Advanced resistance welding machine with great price

  • 1 - 4 Sets
    $25,000.00
  • >=5 Sets
    $23,000.00
Wire Diameter:
3-6mm
Lead Time:
Quantity(Sets) 1 - 2 >2
Est. Time(days) 50 Negotiable
Customization:
Program (Min. Order: 1 Sets)
Report Suspicious Activity
Overview
Quick Details
Warranty:
1 year
After-sales Service Provided:
Online support, Video technical support, Field installation, commissioning and training, Field maintenance and repair service, Engineers available to service machinery overseas
Condition:
New
Power (kW):
215
Applicable Industries:
Industrial
Key Selling Points:
High speed
Weight (KG):
2500
Machine Type:
Wire Mesh Welding Machine
Product Name:
Advanced resistance welding machine with great price
Wire diameter:
3-6mm
Manufacture:
jiaoyang
Width of mesh:
1600mm
Control system:
PLC
Certification:
CE,ISO9001
Finished product:
fence mesh
Mesh length:
3.5/5.5/7.5m
Welding speed:
80times/min
Supply Ability
Supply Ability:
30 Set/Sets per Month
Packaging & Delivery
Packaging Details
PACKED IN WOODEN CASE
Port
XINGANG,TIANJIN
Lead Time :
Quantity(Sets) 1 - 2 >2
Est. Time(days) 50 To be negotiated
Advanced resistance welding machine with great price
20150708_112656_Jc

Below information is required for quick quotation:

 1. Wire diameter :   From         mm to         mm.

 2. Line wire space : From        mm to             mm.

     Cross wire space : From        mm to             mm.

 3. Mesh width: 1200mm ~1500mm~2100mm~2500mm~3000mm ( customized)

 4. Industrial voltage : 380V  50HZ ( Customized)

 5.  Do you want to weld wire mesh panel or mesh in coil ?

 6.  Is the auxiliary equipment also require ?





Fence Mesh Welding Machine

Item

GWC-1200C

GWC-1600C

GWC-2100C

GWC-2500C

Number of Electrodes

24

32

40

48

Max. Mesh Width

1200mm

1600mm

2100mm

2500mm

Wire Diameter

3-6/4-8mm

3-6/4-8mm

3-6/4-8mm

3-6/4-8mm

Cross Wire Space

50-200mm

50-200mm

50-200mm

50-200mm

Line Wire Space

50-200mm

50-200mm

50-200mm

50-200mm

Electric Capacity

400KVA

500KVA

630KVA

800KVA

Welding Speed

30-60t/min

30-60t/min

30-50t/min

30-50t/min

Control System

PLC Control

PLC Control

PLC Control

PLC Control

Special specification is available according to your requirements.



Advantage:

1. PLC control with touch screen in English and Chinese. Cross wire pitch is SET though PLC, different size is available.

2. Cross wires are automatic fallen by step motor.



MachineProduct

resistance welding machine

resistance welding machine







Construction Mesh Welding Machine

Item

GWC-1200B

GWC-1600B

GWC-2100B

GWC-2500B

Number of Electrodes

24

32

40

48

Max. Mesh Width

1200mm

1600mm

2100mm

2500mm

Wire Diameter

3-6/4-8mm

3-6/4-8mm

3-6/4-8mm

3-6/4-8mm

Cross Wire Space

50-200mm

50-200mm

50-200mm

50-200mm

Line Wire Space

50-200mm

50-200mm

50-200mm

50-200mm

Electric Capacity

400KVA

500KVA

630KVA

800KVA

Welding Speed

30-60t/min

30-60t/min

30-50t/min

30-50t/min

Control System

PLC Control

PLC Control

PLC Control

PLC Control

Special specification is available according to your requirements.



Machineproduct
resistance welding machineresistance welding machine









Reinforce Mesh Welding Machine

Item

                       GWC-2500C

Number of Electrodes

24

Max. Mesh Width

2500mm

Wire Diameter

4-8mm/5-12mm

Cross Wire Space

50-100mm-300mm

Line Wire Space

50-100mm-300mm

Electric Capacity

800KVA

Welding Speed

30-50t/min

Control System

PLC Control

Special specification is available according to your requirements.







Machineproduct
resistance welding machine

resistance welding machine





Our company
  1. Hebei Jiaoyang Wire Mesh Machine CO., LTD.
  2. Employees: 243Professional diamond wire mesh machine with great price
  3. Engineers and technicians: 34
  4. Processing equipment: 105 sets
  5. Plant area: 133,000 square meters
  6. Office area: 3,700 square meters
  7. National patents: 63
  8. Assets: USB 20,000,000
  9. Annual equipment export amount: 360 sets
  10. Annual equipment output: 800 sets
  11. Foreign markets: Asia, Middle East, America, Africa
